FRAME
|
Factor 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 100mm travel, one piece bolt-on upper link, QR 9mm rear axle, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design. 26" wheelset compatible
|
|
SIZES
|
One size: 300mm
|
|
REAR SHOCK
|
X-Fusion 02PRO R, 210x47.5mm. Settings: low-speed rebound, air preload. 45x8mm top and bottom bushings
|
|
SHOCK SETTINGS
|
A-Tune light compression
|
|
FORK
|
X-Fusion Velvet RL 26, 100mm, air spring, tapered steerer tube, 9x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
|
|
HEADSET
|
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45°
|
|
STEM
|
Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore
|
|
HANDLEBAR
|
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
|
|
GRIPS
|
Onoff Twin, 1lock-on
|
|
SEATPOST
|
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
|
|
SADDLE
|
SDG Fly JR
|
|
FRONT BRAKE
|
Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
|
|
REAR BRAKE
|
Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
|
|
BRAKE LEVER
|
Sram Level, tooled reach adjust, lever pivot bushings
|
|
RIMS
|
MDK-XP1 24 TLR, 23mm internal width, tubeless ready, 32 spokes
|
|
SPOKES
|
CN round stainless steel
|
|
FRONT HUB
|
Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
|
|
REAR HUB
|
Formula DC22LW 9x135mm, cup & cone ball bearings, IS 6 bolts
|
|
FRONT TIRE
|
Kenda Booster 24x2.4 single compound 30TPI, wire bead
|
|
REAR TIRE
|
Kenda Booster 24x2.4 single compound 30TPI, wire bead
|
|
CRANKSET
|
Sram SX Eagle, DUB axle, Direct mount chain ring, 155mm
|
|
RINGS
|
30T, steel, X-Sync
|
|
BOTTOM BRACKET
|
Sram DUB BSA, sealed bearings, 73mm
|
|
PEDALS
|
-
|
|
CHAIN
|
Sram SX Eagle, 12s, Powerlock
|
|
FRONT DERAILLEUR
|
-
|
|
REAR DERAILLEUR
|
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
|
|
SHIFT LEVERS
|
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
|
|
CASSETTE
|
Sram PG-1230, 11-50T, 12s
|
|
MOTOR
|
-
|
|
BATTERY
|
-
|
|
DISPLAY
|
-
|
|
DERAILLEUR HANGER
|
Mondraker M073
|
|
OTHERS
|
-
|
|
WEIGHT
|
13.2kg
|
